Name of the Project
Square Kilometre Array (SKA) project.

Location
Africa and Australia.

Project Owner/s
The international SKA project is run by the UK-based SKA Organisation, which currently comprises Australia, Canada, China, Germany, Italy, the Netherlands, New Zealand, South Africa, Sweden and the UK. India is an associate member and is expected to become a full member shortly.

The SKA Organisation formalises relationships between the international partners and centralises the leadership project.

The project in South Africa is the responsibility of a separate, local organisation, SKA SA.

Project Description
The SKA will provide a collecting area of one-million square metres, which demands a revolutionary break from traditional radio-telescope design.

The project will use three types of antennas (radio-wave receptors) – dishes, midfrequency aperture arrays and low-frequency aperture arrays – to provide continuous frequency coverage from 70 MHz to 10 GHz. Combining the signals from the antennas will create a telescope with a collecting area equivalent to a dish with an area of about 1 km2.

The first phase of the SKA, known as SKA1, will result in the creation of two complementary instruments, one each in South Africa and Australia.

The South African instrument, known as SKA1_Mid, will comprise about 200 dishes and operate in the 350 MHz to 14 GHz frequency range. The Australian instrument, known as SKA1–Low, will comprise more than 100 000 (perhaps as many as 130 000) dipole antennas and will operate in the 50 MHz to 350 MHz frequency range.

SKA1–Mid will include the 64 dishes of the South African precursor to the SKA, the MeerKAT radio telescope array, being built in the Karoo region. Australia’s precursor, the Australian SKA Pathfinder (better known as Askap and already in operation) will serve as surveying instrument for the SKA.

The central regions, in Australia and in South Africa, will contain cores, each 5 km in diameter – one for each antenna type. Fifty per cent of the collecting area will be within the central cores. The aperture array antennas will extend to about 200 km from the core regions. In Africa, the dishes will be positioned at distant stations that are 3 000 km from the core regions.

The construction of the SKA will be phased.

Phase 1 (SKA1) will comprise about 10% of the array and will include dishes and low-frequency aperture arrays.

The Australian SKA Pathfinder and South Africa’s Meerkat precursor dishes will be incorporated in the SKA1. The Murchison Widefield Array, located at the Australia site, is another precursor telescope to the SKA.

Phase 2 (SKA2) will extend the array with midfrequency aperture arrays and further dishes.

All the dishes for SKA2 will be located in Africa. All the low-frequency aperture arrays will be located in Australia and all the midfrequency aperture arrays will be built in Southern Africa.

The phased construction of the telescope will mean that the SKA can start operating before construction is completed.

Potential Job Creation
More than 1 000 engineers and scientists in 20 countries have been involved in designing the SKA over the past five years, with new research programmes and educational initiatives and collaborations being created in various countries to train the next generation of space scientists and engineers.

Capital Expenditure
SKA1 is expected to cost €650-million (about R8.9-billion).

Planned Start /End Date
Construction of the first phase of the SKA is expected to start in 2021.

Latest Developments
The South African Radio Astronomy Observatory (Sarao) has announced that the international consortium of computing specialists that includes South Africans, which has been developing the Science Data Processor (SDP) for the SKA, has completed its engineering design work on the system. The consortium, led by the UK’s University of Cambridge, has involved almost 40 institutions in 11 countries.

The SDP project involved the design of the computing hardware, software and algorithms required to take the enormous amounts of data that will be provided by the SKA and process it into science data products, or astronomical images. The SDP will comprise supercomputers in South Africa and Australia.

The South African institutions involved were Sarao, the Council for Scientific and Industrial Research’s Centre for High-Performance Computing, the University of Cape Town, and the  Space Advisory Company (SAC) and Eclipse Holdings. Awarded funding under Sarao’s Financial Assistance Programme (FAP), SAC and Eclipse seconded a total of four engineers to the SDP consortium.

South Africa and Australia will co-host the core elements of the SKA telescope. South Africa will have the midfrequency element of the SKA (known as SKA-Mid for short) and Australia will have the low-frequency element (SKA-Low). The two SDP supercomputers will be located in Cape Town and Perth.

Key Contracts and Suppliers
None stated.

On Budget and on Time?
The project is reportedly on course.

Contact Details for Project Information
SKA South Africa head communication and stakeholder relations Lorenzo Raynard, cell +27 71 454 0658 or email lraynard@ska.ac.za.
